Available frequency range: 20 Hz to 200 MHz
Range with constant transducer factor（-3dB): 300kHz to 100 MHz
Transducer factor reduced by 20 dB/decade in range(-3dB): 20 Hz to 300 kHz
RF connector: N female
Effect by external magnetic fields Suppression of indication from current-carrying conductors next to probe: >40 dB
Max. DC current or peak AC current: 200 A (f < 1 kHz)
RMS value of RF current: 1 A (f > 1 MHz)
AC (RMS value): 6A (f < 1 kHz)
Operating temperature range: –10 °C to +55 °C
Storage temperature range: –25 °C to 70 °C
Permissible core temperature: 80 °C
Dimensions L × W × H: 78x26x71 mm
Inner diameter: 22 mm
Weight: 260g
RF current testing (external 50Ω through load):
Output impedance: 50Ω (f ≥ 10 MHz)
VSWR: <2 (f > 10 MHz)
Insertion impedance: ≤0.8Ω
Transfer impedance In range with constant transducer factor ZT: 3.16Ω
Transducer factor k1) in range with flat frequency response (Figure 1): -10dB (1/Ω)
Load capacity dropping to: 0.2A (f < 1MHz)/ 2W (f > 1 MHz)
RF current injection:
Output impedance: N/A
VSWR: N/A
Insertion impedance: ≤1Ω
Transfer impedance In range with constant transducer factor ZT: 7.1Ω
Transducer factor k1) in range with flat frequency response (Figure 1): -17dB (1/Ω)
Load capacity dropping to: 0.45A (f < 1MHz)/ 10W (f > 1 MHz) 50W (15min)
