Current range: 50mA~10A Peak (L); 1A~100A Peak (H)
Attenuation accuracy: 0.1V/A (L); 0.01V/A (H)
Typical DC precision: 3%±50mA (L); 500mA~40A Peak: 4%±50mA；40A~100A Peak: ±15% Maximum (H)
Band-width (-3dB): DC-2MHz
Phase shift: DC～65Hz：<1.5° (L); DC～65Hz：<1° (H)
Typical DC linearity: The typical DC linearity at H level(0.01V/A), Figure 4
Rise time: ≤175ns
Max operation current: Please refer to voltage and current rating table
Max operation voltage: Please refer to voltage and current rating table
Max floating voltage: Please refer to voltage and current rating table
Operating voltage RMS: CATI 600V CATII 600V CATIII 300V
Common mode voltage RMS: CATI 600V CATII 600V CATIII 300V
Typical battery type and life.: 9V alkaline layer-built battery/ 15H
Low power indication: When battery voltage is lower than 6.5V, battery indicator will turned red and alert.
Overload indication: When the current under test surpasses the range, the buzzer will buzz
