Dimensions: 270x225x156 mm
Weight 3.2 kg
Input sensor
Sensor inputs (digital / analogue) depending on the configuration
RS 485 / ModBus RTU digital sensor
Third party sensors are analog 0/4 - 20 mA, 0 - 1/10/30 V, pulse,
Pt100 / Pt1000.
Measuring range
Dew Point: -80 ... + 50 ° Ctd
Temperature: -20 ... 70 ° C
Humidity: 0 ... 100% RH
Pressure: 0 ... 16 Bar
Accuracy
± 1 ° C: 20 ... -20 ° Ctd
± 2 ° C: -20 ... -50 ° Ctd
± 3 ° C: -50 ...- 80 ° Ctd
Pressure: ± 0.5%
Power supply for sensor
Output voltage: 24 VDC ± 10%
Interface: USB-Stick,
Ethernet RTU / TCP option,
WEB-Server option
Memory Card: 4 GB-Memory Card-Standard
Provide energy:
Li-Ion battery,
Power supply 100 - 240 VAC / 50 - 60 Hz with 12VDC output
3.5 "color screen -Touchpanel TFT transmissive, graphic, curve, statistics
Operating Temperature 0 - 50 ° C
Storage temperature -20 to +70 o C
Connect the 6mm plug-in connector
Optional Ethernet Modbus TCP
Webserver option
Optional mathematical calculation function
