Temperature range: -40 to 100 ℃
JTM K07
Temperature fluctuation (100.0℃ or lower): ±0.3 ℃
Temperature fluctuation (100.1℃ or higher): -
Temperature gradient (100.0℃ or lower): 4.0 ℃
Temperature gradient (100.1℃ or higher): -
Spatial temperature deviation (100.0℃ or lower): 3.0 ℃
Spatial temperature deviation (100.1℃ or higher): -
For JTM K09 K07
Temperature change rate (Drop): 1.0℃/min. (86 to -26℃)
Temperature change rate (Rise): 2.0℃/min. (-26 to 86℃)
Time to reach temperature extreme (Drop): Within 70 min. (20 to -40℃)
Time to reach temperature extreme (Rise): Within 40 min. (20 to 100℃)
Testing chamber volume: 1,500 L (Width 1,000 x Depth 1,500 x Height 1,000 mm)
Product dimensions: Width 1,470 × Depth 2,070 × Height 2,000 mm
Exterior coating color: Natural gray (Munsell code: 1.0Y8.5/0.5)
Cooling method: Water-cooling, single-stage compression refrigeration x 2; Refrigerant: R404A
Controller: Operation modes: Set-point or program operation (Steps: 20 per pattern, Repetitions: Max. 98 and infinite)
Safeguards: Earth leakage circuit breaker, operation circuit fuse, electric motor overload safeguard, high-voltage shutdown system, excess temperature increase prevention system, heater overcurrent safeguard, etc.
Equipment: Observation window, chamber light, cable hole, casters, and level adjusters
Accessories: Shelf support, shelf, fuse, Y strainer, rubber plug, and instruction manual
Coolant: 2,400 L/h (coolant inlet temperature 32°C), Pressure: 0.1 to 0.5 MPa, Piping diameter: Rc1
Power supply: Three-phase 200V 50/60Hz, Three-phase 220V 60Hz, Three-phase 380V 50Hz
Maximum load current: 50 A
Product weight: 830 kg
