Measured value: Temperature, Relative humidity, Counted values (dew point…), Atmospheric pressure
Temperature sensor:
Measuring range: -30 to +80 °C
Accuracy: ±0.4 °C
Resolution 0.1 °C
Humidity sensor:
Measuring range: 0 to 100 % RH
Accuracy: ±2.5 % RH from 5 to 95 % at 23 °C
Resolution: 0.1% RH
Dew point:
Measuring range: -60 to +80 °C
Accuracy: ±1.5 °C at ambient temperature T <25 °C and RH >30 %
Resolution: 0.1 °C
Atmospheric pressure sensor:
Measuring range: 600 to 1100 hPa
Accuracy: ±1.3 hPa at 23 °C from 800 to 1100 hPa
Resolution: 0.1 hPa
Operating temperature: -30 to +80 °C
Channels: internal sensor of temperature, humidity sensor and atmospheric pressure
Counted values: dew point, absolute humidity, specific humidity, mixing ratio, specific enthalpy
Output: RS232
Range of humidity sensor temperature compensation: all temperature range
Available temperature units: degrees Celsius, degrees Fahrenheit
Communication protocol: ModBus RTU and Advantech ADAM compatible protocol
Power: 9-30 Vdc
Protection class: IP54 electronics; IP40 sensors
Dimensions: 88.5 x 114 x 39.5 mm; length/diameter of external probe: 88/18 mm
External probe cable length: 1 meter
Weight: approx. 210 g
Included in delivery:
T7310
Instruction Manual
Traceable Calibration Certificate
FREE software TSensor for Configuring of the Transmitter
