Cometech QC-657 ເຄື່ອງກວດຈັບຄວາມຮ້ອນ HDT (1 ສະຖານີ)
Temperature: Room temperature - 300℃
Temperature Control: 2℃ increase per minute
Weight: Weight support 3 N.
Each station has the following weights: 0.1N×1, 0.2N×2, 0.5N×1, 1N×1, 2N×2, 5N×1, 10N×1
Deflection Reading: 0.001~3.000 mm
Flexion Span: 100 mm (max), 50mm (adjustable)
Specimen Support’s Surface: R=3.0 mm
Specimen Dimension:
ASTM L=5”(127 mm), d=1/2 ”(12.7 mm), b=1/4”( 6.35 mm)
ISO edge wise L=120mm, d=10mm, b=4mm
ISO flat wise L=80mm, d=10mm, b=4mm
※Specimen deviation should be±0.1 mm
Features:
1. 7” colored touch screen that shows multiple test data
2. All of the data is completely recorded and the data can be converted to graph.
3. User-friendly operation that guides users step by step.
4. Jigs can be replaced for Vicat test
Cooling Method: Water cooling
Test Stations: 1 station
Power: Sigle Phase 220VAC
Dimension: 85 X 48 X 54 cm
