Comchip Technology KBPC1504W-G ສະຕະປະຟອນບຣິດຈ໌ຟາສເອັກ 15A 400V

Width: 28.8 mm

Height: 11.23 mm

Length: 28.8 mm

Unit Weight: 26 g

Mounting Style: Screw Mount

Max Surge Current: 300 A

Termination Style: Through Hole

If - Forward Current: 15 A

Ir - Reverse Current: 10 uA

Peak Reverse Voltage: 400 V

Vf - Forward Voltage: 1.1 V

Vr - Reverse Voltage: 400 V

Maximum Operating Temperature: + 150 C

Minimum Operating Temperature: - 55 C
