Cirrus CR151B Optimus yellow Class 1 ເຄື່ອງວັດແທກລະດັບສຽງ (20~140 dB, Data Logging)
-Applicable Standards
IEC 61672-1:2013 Class 1
IEC 61672-1:2002 Class 1
IEC 60651:2001 Type 1 I
ANSI S1.4 -1983 (R2006), ANSI S1.43 - 1997 (R2007)
ANSI S1.25:1991
-Microphone
Class 1 MK:224 pre-polarized,
-Microphone Preamplifier: MV:200 Removable Preamplifier (All versions)
-Total Measurement Range:
20dB to 140dB RMS Single Range
Noise Floor:, <21dB(A) Class 2
-Frequency Weightings : RMS: A, C, & Z Measured Simultaneously
-Time Weightings: Fast, Slow & Impulse Measured Simultaneously
-Display: High resolution display. Ambient light sensor & illuminated keypad
-Memory: 4GB (B Version), 32GB factory fit option
-AuditStore: Measurement verification data stored in secure memory
-Time History Data Rates (Global settings): 10ms, 62.5ms, 125ms, 250ms, 1/2 sec, 1 sec, 2 sec (User selectable)
-VoiceTag Audio Recording (B Version): Up to 30 seconds of audio notes with each measurement
-Measurement control: Pause & Back Erase with user selectable duration
-Size: 283mm x 65mm x 30mm
-Weight: 300gms/10oz
-Batteries: 4 x AA Alkaline
-Battery life
Typically 12 hours with Alkaline AA
Typically 20 hours with Lithium AA Non-Rechargeable
Battery life is dependent upon the battery type, quality & screen brightness
-Connections
USB Type B to PC
AC & DC Output via ZL:174 (2 x Phono, 1m)
Multi-pin IO for external power via ZL:171 cable (2.1mm socket)
External Power: 5v-15v via MultiIO socket via ZL:171 cable (2.1mm socket)
-Tripod Mount: 1/4" Whitworth socket
-Case: Material: High Impact ABS-PC with soft touch back & keypad
-Environmental
Temperature: Operating -10°C to +50°C, Storage -20°C to +60°C
Humidity: Up to 95% RH Non Condensing
-Electromagnetic performance
IEC 61672-1:2002 & IEC 61672-2:2003
Except where modified by EN 61000-6-1:2007 & EN 61000-6-1:2007
-Language options: English, French, German, Spanish. Other language options may be available
-Software Support: NoiseTools Download, Configuration & Analysis software supplied as standard. Compatible with Microsoft Windows XP, Vista, 7 & 8 (32bit & 64bit)
-Displayed Functions
LXY, LXYMax, LXYMin
Measurement Run Time
-Stored Functions
LXYMax & Time History of LXYMax
Time & Date of Measurement Start
where x=A ,C ,Z; y= F, S, I
Other functions may calculated by the NoiseTools software and displayed on download.
