Data Acquisition
Direction: X, Y, Z
Range frequency: 0.5 ‐ 250 Hz
Range velocity: ±50 mm/s (±2 in/s)
Range acceleration: ±4 g
Measurements: PPV, PPA, PVS, VDV, Velocity traces
Noise (RMS): 50 um/s at 250 Hz BW (2 mil/s)
Resolution: 1 um/s (0.04 mil/s)
Dominant frequency determination: FFT
Applications: Construction (metric)
GPS Location
Sensor type: GPS receiver
Accuracy: 10 meter CEP (33 ft CEP)
Sensor Tilt: Maximum velocity level: 50 mm/s (2 in/s)
Logging Interval Time: Range: 2 ‐ 6000 seconds
Alarm Trigger Level: Range (PPV): 0.2 ‐ 50 mm/s (0.008 ‐ 2 in/s)
Applicable Standards
SBR‐A / DIN4150‐3 / BS7385 / Circulaire du ’86 / ISEE
(USBM RI 8507 & OSMRE) / SN 640 312a / IN 1226
Communication
Wireless: WiFi, 4G/LTE
Modem: Network 4G/LTE
Internal Memory: Storage records: ~ 1 work week storage of log
Ambient Condition
Ingress protection rating: IP65
Operating temperature range: ‐10°C to 70°C (14°F to 158°F)
Storage temperature range: ‐30°C to 90°C (‐22F° to 194°F)
Power Supply
Power source: External
Minimal power supply: 5V USB power (min. 4.5V, max. 5.5V), min. 1A (5W)
Power consumption: 25mW sleeping, 1W idle, 3W active, 5W max
Calibration
Recommended biennial (every two years)*
Certified calibration by a Omnidots certified facility
*When used according to product manual and within ambient specifications.
Dimensions: 109 x 130 x 45 mm (4.29 x 5.12 x 1.77 inch)
Weight: 260 gr (9.17 oz)
Sensor Positioning
Mounting: 1 screw and 1 plug included
Auto levelling; Auto axes alignment: Automatic adjustment by gravity
