Cincon CFM25S150 ຕົວແປ AC-DC ພາວເພີ້ມ AC-DC, ກະບອງເປີດ, 25 ວັດ, ອອກພິມດຽວ, ອອກພິມ 15VDC, 1.67A, ປະສິດທິພາບ 85%, PCB

Width: 27.94 mm (1.1 in)

Height: 24.9 mm (0.98 in)

Length: 50.8 mm (2 in)

Industry: Industrial

Efficiency: 85 %

Unit Weight: 50 g

Output Power: 25 W

Input Voltage: 90 VAC to 264 VAC

Mounting Style: PCB

Input Frequency: 47 Hz to 63 Hz

Load Regulation: Regulated

Isolation Voltage: 3000 Vrms

Number of Outputs: 1 Output

Open Frame/Enclosed: Open Frame

Output Current-Channel 1: 1.67 A

Output Voltage-Channel 1: 15 VDC

Operating Temperature Range: - 30 C to + 70 C

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 30 C
