Max Cutting Length: 450mm
PCB Material: FR1, FR4, CEM1, CEM3, MCPCB
Display: PLC
PCB Thickness: 0.3-3.5mm
Blade Material :Japan High Speed Steel
Applications: Mobile/Computer/LED boards etc
Features:
Wedge-shaped knives shear the entire groove without bending or tension. Independent lab tests show less than 200 microstrains of stress measuring compression and tension.
Separates boards up to 450mm x 3.5mm thick.
Separating metallized boards or FR4 boards of any length.
Minimum board thickness of 0.3mm
Shears boards safely with parts as close as 0.5mm to the score line, including ceramic capacitors
Operator foolproof! Panels cannot be inserted into the knives except on the score line
Pneumatically driven
Handles high components up to 1"
Bow waves that can occur with round knives are avoided
Easy adjusting of distance between knives
Edge distance guide for separating scored boards
