Detection limit
Loop
Benzene & Toluene: ~ 1 ppb
Ethylbenzene & m+p-Xylenes: ~ 2 ppb (with default settings) / o-Xylene: ~ 4 ppb
Configuration & cycle time
Loop
BTEX: 10 min
Benzene + 1.3 butadiene: from 10 to 15 min
Benzene: 5 min (3 min in option)
Other application on demand
Detection range
Loop
0-1000 ppb
0-10 ppm / 0-100 ppm / 0-1000 ppm
Measurement
Detector: PID
Temporal resolution: 0.1 seconds
Response time: One measurement every 10 minutes (default settings)
Analysis sample condition: Gas T°: 5 - 40°C; Gas RH: 20 - 90%; Atmospheric pressure
Calibration: Gaseous BTEX mixture or gaseous Benzene
Sampling
200μL loop or carbon trap
Gas flow rate: between 10 to 100 mL min-1
Carrier gas: Nitrogen 4 bar inlet pressure and 2.5 mL min-1
Supply inlet connection: 1/8’’
Instrument supply
Power supply: Input 100 - 240V ±10%; 1.5 A max; 47 - 63 Hz - Output 15V; 6.67A 100W
Autonomy on battery: Up to 4h
Power consumption: max 75 W
General
Dimensions (analyzer): 32×28×15 cm; 6.0 kg
Dimensions (suitcase): 56 x 45 x 25 cm; 18 kg
Operational conditions: 0 - 40°C / 20 - 80% RH
Storage conditions: -20°C - +40°C / 0 - 85% RH
Display: 7” TFT display; resolution 800 x 480; integrated touchscreen
Autonomy: BTEX version: 21 days for Gas - 4 hours for battery. Can be reduced for different applications
