CHROMA 63303A ໂມດູນໂຫຼດ (60A/80V/300W)
Power: 30W/ 300W
Current: 0~6A/ 0~60A
Voltage: 0~80V
Min.OperationVoltage(DC) (Typical):
0.4V@3A/ 0.4V@30A
0.8V@6A/ 0.8V@60A
Constant Current Mode
Range: 0~6A/ 0~60A
Resolution: 1.5mA/ 15mA
Accuracy: 0.1%+0.1%F.S./ 0.1%+0.2%F.S
Constant Resistance Mode
Range:
0.025Ω~100Ω (300W/16V)
1.25Ω~5kΩ (300W/80V)
Resolution: 12 bits
Accuracy:
100Ω: 0.1 Ω + 0.2%
5kΩ: 0.01 Ω + 0.1%
Constant Voltage Mode
Range: 0~80V
Resolution: 20mV
Accuracy: 0.05% ± 0.1%F.S.
Constant Power Mode
Range: 0~30W/ 0~300W
Resolution: 7.5mW/ 75mW
Accuracy: 0.5% ± 0.5%F.S
Dynamic Mode
Dynamic Mode: C.C. Mode
T1 & T2:
0.025ms ~ 50ms / Res: 5µs
0.1ms ~ 500ms / Res: 25µs
10ms ~ 50s / Res: 2.5ms
Accuracy: 1µs/1ms+100ppm
Slew Rate: 0.001~0.25A/µs/ 0.01~2.5A/µs
Resolution: 0.001A/µs/ 0.01A/µs
Min. Rise Time: 10µs (Typical)
Current: 0~6A/ 0~60A
Resolution: 1.5mA/ 15mA
Current Accuracy: 0.4%F.S.
