- Voltage: 0–60V
- Current: 0–100A, 0–500A, 0–1000A
- Power: 0–6000W
Static Mode
+ Minimum operating voltage (typical DC)12: 0.6V @ 1000A
+ Constant Current (CC) mode
Range: 0–100A, 0–500A, 0–1000A
Accuracy: 0.05% + 0.05% F.S.
+ Constant Resistance (CR) mode
Range: 0.0012Ω–12Ω (6V/6kW); 0.0048Ω–48Ω (30V/6kW); 0.12Ω–240Ω (60V/6kW)
Accuracy: Vin/Rset (0.2%) + 0.5% IF.S.*
+ Constant Voltage (CV) mode
Range: 0–6V, 0–30V, 0–60V
Accuracy: 0.025% + 0.025% F.S.
+ Constant Power (CP) mode
Range: 0–600W, 0–3000W, 0–6000W
Accuracy: 0.2% + 0.2% F.S.
Dynamic Mode
+ Current slew rate: 1mA/µs–2A/µs; 5mA/µs–10A/µs; 10mA/µs–20A/µs
+ Resolution: 1mA/µs; 5mA/µs; 10mA/µs
+ Accuracy: 5% ± 10µs
Other
+ Power consumption: 200VA (max)
+ Dimensions (H × W × D): 177 × 428 × 647 mm / 6.97 × 16.85 × 25.47 inch
+ Weight: 35 kg / 77.2 lbs
Interfaces
+ Standard: Front USB (Host), Rear USB (Device)
+ Optional: Ethernet / LXI, GPIB, CAN BUS
+ System bus: Master/Slave
General Specifications
+ Operating temperature: 0°C to 40°C
+ Storage temperature: -20°C to 80°C
+ Power supply: 100–240 VAC / 47–63Hz
- Standard accessories: Main unit
