Number of output phases: 1
AC Output
- Power: 1500VA
Voltage
- Output voltage range: 150V/300V/Auto
- Accuracy: 0.2%+0.2%F.S.
- Resolution: 0.1V
- Distortion:
+ 0.3% @ 50/60Hz
+ 1% @ 15-1kHz (Typical)
- Line regulation: 0.1%
- Load regulation: 0.2%
Maximum Current (per phase)
- RMS 12A/6A (150V/300V)
- Peak 72A/36A (150V/300V)
Frequency
- Frequency range: DC, 15 ~ 1kHz
- Accuracy: 0.15%
- Resolution: 0.01 Hz
DC Output
- Power: 750W
- Voltage: 212V/424V
- Current: 6A/3A (212V/424V)
Input Specifications:
- Voltage range: 1Ø 100~240V±10%VLN
- Frequency range: 47 to 63Hz
- Current (per phase): 22A Max. @ 90V
- Power factor: 0.98 Min
Measurement
Voltage
- Voltage range: 150V/300V
- Voltage accuracy: 0.2%+0.2%F.S.
- Resolution: 0.1V
Current
- Range (Peak): 72A
- Current accuracy (RMS): 0.4%+0.3%F.S.
- Current accuracy (Peak): 0.4%+0.6%F.S.
Power
- Accuracy: 0.4%+0.4% F.S.
- Resolution: 0.1W
Temperature Range
- Operating: 0˚C to 40˚C
- Storage: -40˚C to 85˚C
Safety & EMC standards: CE (include EMC & LVD)
Dimensions (H x W x D): 133.35 x 482.6 x 569.5 mm
Weight: 20 kg
