AC Output
- Number of output phases: 1 phase or 3 phase
- Max power: 3kVA
- Power per phase: 1kVA
Voltage
- Voltage range: 0~175V / 0~350V / Auto
- Voltage range with 5kHz option
+ At 15Hz~3000Hz: 0~175V / 0~350V
+ At 3001Hz~5000Hz: 0~115V / 0~230V
- Accuracy: 0.1% of RD + 0.2% of FS
- Resolution: 0.1V
- Distortion:
+ < 0.3% @50/60Hz
+ < 1% @15Hz ~ 500Hz
+ 1% maximum to 500Hz, add 0.5%/kHz up 2kHz
- Line regulation: 0.1%
- Load regulation: 0.2%
Maximum Current (Single-phase mode)
- RMS: 30A / 15A
- Peak (CF=4): 120A / 60A
Maximum Current (Per phase in three-phase mode)
- RMS: 10A / 5A
- Peak (CF=4): 40A / 20A
Frequency
- Frequency range: 15Hz~2000Hz
- Frequency range with 5kHz option: 15Hz~5000Hz
- Accuracy: 0.01%
DC Output (Single-phase mode)
- Power: 3kW
- Voltage: 247.5V / 495V
- Current: 30A / 15A
DC Output (Three-phase mode)
- Power: 1kW
- Voltage: 247.5V / 495V
- Current: 10A / 5A
Input Specifications
- Voltage range: 3Ø 200-240V ±10% VLN (WYE); 3Ø 200-240V ±10% VLL (Delta)
- Current (per phase): 15A Max./Phase (3Ø 200-240V ±10% VLL)
- Power factor: 0.97 (Typical)
Measurement
Voltage
- Voltage range: 0~175V / 0~350V / Auto
- Voltage accuracy: 0.1% of RD + 0.2% of FS
Current
- Current accuracy (RMS): 0.2% of RD + 0.2% of FS
- Current accuracy (Peak): 0.2% of RD + 0.4% of FS
Power
- Accuracy: 0.2% of RD + 0.4% of FS
Power Line Disturbance Simulation (PLD Simulation): LIST, PULSE, STEP functions.
Waveform Synthesis: Up to 50th order at 50/60Hz.
Harmonics Measurement: Voltage and current measurement up to the 50th order at 50/60Hz.
Programmable impedance: 0Ω + 0.2mH ~ 1Ω + 2mH
Efficiency: >80% (Typical)
Protection: OVP, OCP, OPP, OTP, FAN
Safety & EMC standards: CE mark
Dimensions (H x W x D): 221.5 x 425 x 680mm
Weight: 50 kg
