CHN SPEC FS-620 ກ້ອງຖ່າຍຮູບຫຼາຍສີ (4 channels multispectral + 1 RGB + 1 channel thermal infrared LWIR)
Assembly method: 4 channels multispectral + 1 RGB + 1 channel thermal infrared LWIR
Target size: Multispectral: 1/2"; RGB: 1/3"
Effective pixels: Multispectral: 1.3Mpx; RGB: 11.9Mpx; LWIR: 0.3Mpx
Shutter type: Multispectral: Global; RGB: Rolling
Quantization bit number: Multispectral: 12bit; RGB: 8bit
Field of view: Multispectral: 54.2°×44.5°; RGB: 49.1°×40.5°
Ground resolution: Multispectral: 9.6cm@H120m; RGB: 2.86cm@H120m
Coverage width: Multispectral: 123mx98m@H120m; RGB: 109mx88m@H120m
Spectral channel:
Multispectral: 555nm@27nm, 660nm@22nm, 720nm@10nm, 840nm@30nm
RGB, LWIR: 8μm–14μm
Optical window: Sapphire optical glass window
Host size: 182mmx169mmx129mm (including gimbal)
Host weight: ≤1000g (including gimbal)
Mounting interface: X-Port
Powered by: X-Port
Power consumption: <=43W
Image format:
Multispectral: 16-bit raw TIFF (including GPS)
RGB: 8-bit JPEG (including GPS)
LWIR: 16-bit TIFF (including GPS)
Storage media: Standard 512G solid state drive
Processing software: FigSpec UAV-MS, FigSpec Merge-MS, FigSpec Studio
Parameter setting: DJI Pilot
Shooting trigger: Timing trigger
Shooting frequency: Maximum support 10Hz
Operating temperature: -10°C~+50°C (Relative wind speed ≥1m/s)
Storage temperature: -30°C~+70°C
Ambient humidity: RH ≤85% (non-condensing)
