Chauvin Arnoux CA 5292-BT ບັນທຶກສຽງຫຼາຍຄັ້ງດ້ວຍຈໍສີກຣາບຟິກ (with Bluetooth)
Manufacturer: Chauvin Arnoux
Model: CA 5292-BT
Order No.: P01196812
Origin: France
Warranty: 12 months
DC, AC and AC+DC voltages TRMS
Range: 100 mV */ 1000 mV / 10 V / 100 V / 1000 V
Resolution: 1 μV / 10 μV / 0.1 mV / 1 mV / 10 mV
AC and AC+DC bandwidth: 100 kHz
DC accuracy: 0.03%
AC and AC+DC (VLowZ) accuracy: 0.3% 0.3%
DC, AC and AC + DC TRMS current
Range: 1000 μA / 10 mA / 100 mA / 1000 mA / 10 A / 20 A (30s max on 100 A range)
Resolution: 10 nA / 0.1 μA / 1 μA / 10 μA / 100 μA / 1000 μA
DC / AC and AC+DC accuracy: 0.08% / 0.3%
AC and AC+DC bandwidth: 50 kHz
Frequency
Frequency range: 10 Hz / 100 Hz / 1 kHz / 10 kHz / 100 kHz / 1 MHz / 5 MHz
Resolution: 0.0001 Hz / 0.001 Hz / 0.01 Hz / 0.1 Hz / 1 Hz / 10 Hz / 100 Hz
Resistance and continuity
Ranges: 100 Ω */ 1 kΩ / 100 kΩ / 1000 KΩ / 10 MΩ / 100 MΩ
Resolution: 0.001 Ω / 10 mΩ / 100 kΩ / 10Ω / 10Ω / 1 kΩ
Basic accuracy: 0.07%
Protection: 1000 V electronic protection
Audible continuity detection: 1000 Ω / SIGNAL <20 Ω < 3.5 V
Diode test
Threshold voltage measurement: Diode 0 -2.6 V <1 mA + Zener diode or LED 0-2.6 V <11 mA
Capacitance
Ranges: 1 nF / 10 nF / 100 nF / 1000 nF / 10 μF / 100 μF / 1 mF / 10 mF
Resolution*: 1 pF / 10 pF / 0.1 nF / 1 nF / 0.01 μF / 0.1 μF / 1 μF / 10 μF
Temperature with Pt100/1000 and K/J thermocouples
Operating range: -200 °C to +800° C with Pt and -40 to +1200 °C with K thermocouple
Accuracy: 0.1 %
Other Measurement functions
SURV MAX/MIN/AVG: Time/date-stamped on all the main positions
REL: Reference-delta relative value on 3 displays + main measurement
PWM flter: 4th order 300 Hz low-pass flter for measurements on variable speed drives of asynchronous motors
SPEC Display of the measurement tolerance + Smin + Smax
GRAPH: Trends of main measurements with max., variable time and display of waveform (50/60 and 600 Hz)
Secondary measurements: 3 measurements + main measurement
Measurement storage: 10,000
General specifcations
Type of display: Colour graphical (70x52) with backlighting and black background on 4 x 100,000-count displays
PC interfaces: With bluetooth– SX-DMM software and ANDROID application
Power supply: USB-type charger or 4 AA batteries or NiMH rechargeable batteries
Safety / EMC: Safety as per IEC 61010-1, IEC 61010-2-033 1000 V-CAT III /600 V CAT IV EMC as per EN 61326-1
Environment Storage: -20 °C to +70 °C – Operation: 0 °C to +40 °C
Mechanical specifcations: Dimensions (L x W x H): 196x90x47.1 mm –Weight: 570 g
STATE AT DELIVERY
4 x 1.5 V NiMH rechargeable batteries
1.5 m straight/straight red cable
1.5 m straight/straight black cable
Red CAT IV 1 kV test probe
Black CAT IV 1 kV test probe
USB optical communication cable + SX-DMM software
USB charger + USB connection cable
User’s Manual on CD and multilingual start-up guide on paper
OPTIONS
Calibration software............P01196770
Kit of 4 NiMH batteries...........HX00518
