Sensor: ultra-thin alumina capacitive sensor
Measure range: -60~+20°C
Accuracy: ±3°C(-80~-60°C); ±2°C(-60~+20°C)
Repeatability: ±0.5°C
Zero drift: ±1%FS/7d
Range drift: ±1%FS/7d
Response time: T90<30s
Protection level: IP64
Calibration cycle: one year(recommended)
Power supply: 24VDC
Analyzer power consumption: <20VA
Communication: RS485(standard)/RS232(optional)
Environment temperature: 0~45°C
Environment humidity: <90%RH
Alarm output: 1 set; Relay contact point capacity:24V DC,0.2A
Analog output: 1 set,4-20mA/0-20mA/0-1V/0-5V/0-10V/1-5V,(You can set the mode freely). The load:less than 500 Ω
Sample flow rate: 3~5L/min
Sample gas pressure: atmospheric conditions±10% (Gas outlet should be atmospheric conditions)
Inlet and outlet: Gas interface:1/4-inch NPT internal thread, stainless steel material (standard 1/4-6 card-plastic joint)
Sensor life: more than 2 years (normal use)
Instrument life: more than 5 years (normal use)
Measuring method: wall-mounted
L×W×H=375×315×179mm; Level of explosion-proof:Exd || CT6 (certification)
