Frequency Range: 9kHz ~ 44GHz
Frequency Reference
• Nominal frequency: 10MHz
• Aging rate: ± 0.5ppm / year
• Temperature stability: ± 0.1ppm (-20℃~+55℃,Comparative to 25℃±10℃)
Sweep Time: Range: 10μs – 6000s (zero Span), Accuracy: ± 1.0% (zero span)
Frequency Readout Accuracy: ± (frequency readout × frequency reference error + 1% × span + 10% × resolution bandwidth)
RBW: 1Hz – 20MHz (1, 2 ,3 ,5, 8 steps)
VBW: 1Hz – 20MHz (1, 2 ,3 ,5, 8 steps)
SSB Phase Noise (Carrier 1GHz, 20℃-30℃)
• ≤-108 dBc/Hz @ 10kHz offset
• ≤-110 dBc/Hz @ 100kHz offset
• ≤-118 dBc/Hz @ 1MHz offset
• ≤-129 dBc/Hz @ 10MHz offset
Displayed Average Noise Level (Preamplifier Off)
Pre-amplifier ON:
• ≤-159dBm(2MHz~9GHz)
• ≤-156dBm(9GHz~6GHz)
• ≤-154dBm(14GHz~21GHz)
• ≤-154dBm(21GHz~32GHz)
• ≤-152dBm(32GHz~40GHz)
• ≤-148dBm(40GHz~44GHz)
• ≤-145dBm(44GHz~50GHz)
• ≤-140dBm(50GHz~54GHz)
Pre-amplifier OFF:
• ≤-140dBm(2MHz~6GHz)
• ≤-138dBm(9GHz~6GHz)
• ≤-136dBm(9GHz~14GHz)
• ≤-136dBm(14GHz~21GHz)
• ≤-135dBm(21GHz~32GHz)
• ≤-133dBm(32GHz~40GHz)
• ≤-130dBm(40GHz~44GHz)
• ≤-126dBm(44GHz~50GHz)
• ≤-123dBm(50GHz~54GHz)
Second Harmonic Distortion: <-70dBc (50MHz ~ 27GHz)
Input Attenuator: Attenuation range: 0~30dB, 2dB steps
Reference Level
• Range: -150dBm~+30dBm, minimum 1dB steps
• Conversion Uncertainty: ±0.50dB (Reference level: 0dBm~-60dBm)
Dimension
• 316.5mm(W)×236.5mm(H)×75mm(D) (Without side strap and interface plug, the back bracket is closed)
Weight
• 3.3kg (without internal battery),
• 3.8kg (with internal battery)
Battery Life: 4.5h
See more detail information in the Datasheet
