Oscilloscope Functions
Display Size: 3.5" color LCD; 320 x 240 pixels
Bandwidth: 10MHz
Real time sample rate: 50MS/s
Risetime: 17.5ns
Glitch Capture: 50ns
Vertical Sensitivity: 20mV to 100V/div
Vertical Resolution: 8 bits
Trigger Mode: Ferr Run, Single Shot, Edge
Trigger Source: CH1
Trigger Coupling: AC/DC
Input impedance: 1MΩ/20pF
Max Input Volatge: 400V(peak)
Cursor Measurement: Voltage and time
Automotive True RMS Multimeter Functions
Voltage DC Maximum/Resolution/Accuracy: 1000V/1μV/±(0.025% + 5)
Voltage AC Maximum/Resolution/Accuracy: 1000V/1μV/±(0.4% + 40)
Current DC Maximum/Resolution/Accuracy: 10A/0.01μA/±(0.15% + 2)
Current AC Maximum/Resolution/Accuracy: 10A/0.01μA/±(0.07% + 5)
Resistance Maximum/Resolution/Accuracy: 50MΩ/0.1Ω/±(0.05% + 2)
Capacitance Maximum/Resolution/Accuracy: 10mF/0.001nS/±(1.0% + 5)
Frequency Maximum/Resolution/Accuracy: 10MHz/0.01Hz/±(0.005% + 1)
RPM(Tach)Maximum/Accuracy: 600 ~ 4000RPM;600 ~ 12000RPM/±(2.5%+2d)
Dwell Angle Maximum/Accuracy: 1CYL, 2CYL, 3CYL, 4CYL, 5CYL, 6CYL, 8CYL, 10CYL, 12CYL/±(2.5%+2d)
Duty Cycle Maximum/Accuracy: 0.1~99.9%/±(1.5%+2d)
Period Maximum/Accuracy: 0.1~20mS/±(3.0%+5d)
Pulse Width Maximum/Accuracy: 0.1~10mS/±(3.0%+5d)
Diode and Continuity: Yes
PC Interface: Bluetooth
Power Supply: 6 hours Li-ion rechargeable battery;AC Adaptor/charger
Size(HxWxD): 220mm x 96mm x 60mm
Weight: 631g
Accessories:
Test leads, Li-ion batteries, Type K temperature probe, Software, gift box with carrying case.
