Auxiliary Supply
Rated Voltage (Un): 415V
Operating Voltage Range: (0.9-1.1)xUn
Power Consumption: 3VA–10VA
Rated Frequency: 50 Hz
Current Input
Rated current: 5A
Power Consumption: 2VA max
Operating Current Range: 50 mA-5.5A
Rated Frequency: 50 Hz
Relay Output
Numbers of outputs: 8
Output Contact: 5A, 250V (NO Contact)
Expected electrical life: >100000 operations at rated Current
Expected mechanical life: >5000000 operations
Control Range
Cosφ setting 0.85 (ind.)-1.00
C/k Setting Automatic / 0.02-1.0
CT Value 5-10000/5
Time Delay (on, off) Between 2 sec.-1800 sec
Over Voltage Values 240-275 (265) V/ 410-480 (475)V
Switching Program PS1 – PS5
Environmental Conditions
Ambient Temperature: -5°C-55°C
Humidity: 5% - 95%
Protection Class: IP 40
Terminal Block Protection Class: IP 00
Equipment Protection Class: Double Insulation-Class ll
Mechanical
Connections: Socket terminals with screw
Dimension (HxWxD): 143x143x67mm
Weight: 0.8kg
