- Operating Modes
Pulse Height Analysis (PHA)
List mode (pulse height and time stamp for each event)
Oscilloscope mode
OMCS (Multichannel Scaling) mode
- Digital Signal Processing
Trapezoidal filter (rise time 0 - 20µs and flat top 0 - 10µs)
Manual trigger threshold adjustment
Manual AC coupled input signal pole/zero adjustment
Baseline restorer
Fast Discriminator
Manual fast discriminator threshold adjustment
Pile up rejection and Live Time correction
- ADC
Resolution:16 bits
Sampling rate: 100 MS/s
- Analog Input
BNC connector
DC and ADC coupled
Positive and negative signals accepted
Programmable coarse gain (x1, x2, x4, x8, x16, x32, x64, x128, x256, x496)
Programmable fine gain (range 0.8 - 2.2 with steps of 0.001)
Gain attenuator (x4)
Programmable DC offset adjustment in the full scale range
- High Voltage Power Supply
SHV connector
V set/I set: ±5 kV/300 µA
HV polarity adjustable
Voltage ripple: 3 mmVpp (Min.), 5 mVpp (Max.)
User configurable Ramp-Up/Ramp-Down rates independently for each channel: 1÷ 500 V/s range in steps of 1 V/s
User configurable HV parameters independently for each channel
OverVoltage/UnderVoltage alarms
OverCurrent/OverTemperature alarms
Channel Inhibit on DB9 and dedicated BNC connectors
Voltage limit, Vmax, software selectable
- Coincidence Modes
Single channel mode (uncorrelated)
Board coincidence (channel 0 con channel 1)
Board anti-coincidence (channel 0 con channel 1)
External Coincidence (GATE)
External anti-coincidence (INH)
- Mechanical: 237 W x 51 H x 195 L mm3
