Broadcom ASMB-KTF0-0A306 ໄຟ LED ຫຼາຍສີ 2220 PLCC4 ສີສາມສີ

Width: 2 mm

Height: 1.9 mm

Length: 2.2 mm

Lens Color: Colorless

Lens Shape: Rectangular

Unit Weight: 200.240 mg

Power Rating: 48 mW, 66 mW, 66 mW

Viewing Angle: 110 deg, 110 deg, 110 deg

Mounting Style: SMD/SMT

Lens Dimensions: 2.2 mm x 2 mm

Lens Transparency: Diffused

Illumination Color: RGB

Luminous Intensity: 490 mcd, 1100 mcd, 215 mcd

Moisture Sensitive: Yes

If - Forward Current: 15 mA, 15 mA, 10 mA

Vf - Forward Voltage: 2 V, 2.95 V, 2.85 V

Wavelength/Color Temperature: 620 nm, 524 nm, 471 nm

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
