Bourns SA85SB0 Thermal Cutoffs HC TCO 85C BL-51

Width: 3.2 mm

Height: 1.17 mm

Length: 5.4 mm

Approvals: UL, cUL, TUV

Tolerance: +/- 5 C

Resistance: 7 mOhms

Unit Weight: 0.050 mg

Contact Rating: 9 VDC / 25 A, 6000 cycles

Voltage Rating: 28 VDC

Maximum Voltage: 28 VDC / 25 A, 100 cycles

Rated Temperature: + 85 C

Reset Temperature: > 40 C

Maximum Temperature: + 85 C

Maximum Leakage Current: 200 mA

Minimum Holding Voltage: 3 V

Maximum Breaking Current: 5 VDC / 60 A, 100 cycles

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 30 C
