- Standard: ISO4287,DIN4768,JIS B,ANSI 146.1
- Measuring range:
Ra: 0.050～10μm/1.000～400.0μ inch
Rq: ----
Rz: 0.020～100μm/0.780～4000μ inch
Rt: ----
- Accuracy: ≤±10%
- Resolution:
+ 0.001μm（reading ＜10μm）
+ 0.01μm（10μm≤ reading ＜100μm）
+ 0.1μm（reading ≥100μm）
- Fluctuation of display value: ≤6%
- Profile digital filter:
Filtered profile: -----
Non- filtered profile: -----
- Sensor:
Radius: 10μm
Material: Diamond
Measuring force: 16mN（1.6gf）
Probe angle: 90°
Vertical radius of guiding head: 48mm
Maximum driving stroke: 17.5mm/0.75 inch
Cutoff length: 0.25mm, 0.8mm, 2.5mm
- Driving speed:
Measuring:
+ Sampling length = 0.25mm When Vt=0.135mm/s
+ Sampling length = 0.8mm When Vt=0.5mm/s
+ Sampling length = 2.5mm When Vt=1mm/s
Returning: Vt=1mm/s
- Evaluation length: 1～5L selectable
- Metric/Imperial: Conversion
- Auto off: √
- Memory: -----
- Pc interface: -----
- Built in Li-ion battery: Rechargeable
- Operating condition:
TEMP: 0～50℃
Humidity: ﹤85%RH
- Dimension: 140×52×48mm（5.5×2.2×1.9 inch）
- Net Weight: 420g
