Bel Power Solutions LRP2660-9B1 ຕົວແປ AC ເປັນ DC AC-DC, ອິນພຸດ 90-264V, ອອກ 24V/24V/6.25A 300W RoHS

Width: 111 mm (4.37 in)

Height: 80 mm (3.15 in)

Length: 168.5 mm (6.634 in)

Industry: Industrial

Approvals: UL/CSA

Dimensions: 168.5 mm x 111 mm x 80 mm

Efficiency: 92 %

Output Power: 250 W

Input Voltage: 90 VAC to 264 VAC, 125 VDC to 300 VDC

Mounting Style: Chassis

Input Frequency: 50 Hz to 60 Hz

Load Regulation: Regulated

Number of Outputs: 2 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 5.2 A

Output Current-Channel 2: 5.2 A

Output Voltage-Channel 1: 24 VDC

Output Voltage-Channel 2: 24 VDC

Maximum Operating Temperature: + 71 C

Minimum Operating Temperature: - 40 C
