Input
Input range: 90 - 264 Vac (wide range) 127 - 300 Vdc
Frequency: 47 - 440 Hz
Inrush current: < 50 A peak @ 230 Vac, cold start @ 25 °C
Input power: < 74 Watts
Efficiency: 75% average
EMI/RFI: FCC Class B conducted; CISPR 22 Class B conducted; EN55022 Class B conducted, VDE0878PT3 Class B conducted
Safety ground leakage current: 275 µA @ 50/60 Hz; 264 Vac input
Output
Maximum power: 45 W for convection; 55 W with 30CFM forced air
Hold-up time: 10/20 ms 115/230 Vac input line
Overload protection: Short circuit protection on all outputs. Case overload protected @ 110% to 160% above peak rating
Overvoltage protection: 6.5 to 7.5 Vdc on the main output
Environmental Specifications
Operating temperature: 0° to 50°C ambient derate each output at 2.5% per degree from 50°C to 80°C. -20°C start up
Storage temperature: -45°C to +85 °C
Electromagnetic susceptibility: Designed to meet EN61000-4; -2, -3, -4, -5, -6, -8, -11 Level 3
Humidity: Operating; non-condensing 10% to 90% RH
Vibration: IEC68-2-6 to the levels of IEC721-3-2
MTBF demonstrated: > 550.000 hours at full load and 25°C ambient conditions
Ordering Information
Output: Triple
1.
Output Voltage: +5 V
Minimum Load: 0.5 A
Maximum Load with Convection Cooling: 5 A
Maximum Load with 30CFM Forced Air: 8 A
Peak Load: 9 A
Regulation: ± 2%
Ripple P/P (PARD): 50 mV
2.
Output Voltage: +12 V
Minimum Load: 0.1 A
Maximum Load with Convection Cooling: 2.5 A
Maximum Load with 30CFM Forced Air: 3 A
Peak Load: 4 A
Regulation: ± 5%
Ripple P/P (PARD): 120 mV
3.
Output Voltage: -12 V
Minimum Load: 0 A
Maximum Load with Convection Cooling: 0.5 A
Maximum Load with 30CFM Forced Air: 0.7 A
Peak Load: 0.7 A
Regulation: ± 5%
Ripple P/P (PARD): 120 mV
