Input
Input voltage range: Universal input (see Note 2) 85 - 264 Vac
Input frequency range: 47 - 63 Hz
Input current (cold start)
120 Vac: 17 A max
230 Vac: 32 A max
Input current:
120 Vac: 1.05 A rms
230 Vac: 0.51 A rms
Output
Output power: Natural convection: 65 W max
Rise time: At turn-on: 1.0 s max
Weight: 283 g (10 oz)
Functions: Safety ground leakage current; Overvoltage protection; Short circuit protection
Environmental Specifications
Thermal performance:
Operating (See derating curve): 0 °C to +70 °C
Non-operating: -40 °C to +85 °C
0 °C to 50 °C, ambient, convection cooled: 65 W
50 °C - 70 °C ambient, convection cooled: Derate to 50% load
Peak (0 °C to 50 °C, 60 s): See table
Relative humidity: Non-condensing: 5 to 95% RH
Ordering Information
Output: Dual
1.
Output Voltage: +5 V
Output Current
Max: 7 A
Peak: 9.1 A
Fan: 8 A
Ripple: 50 mV
Total Regulation: ± 2.0%
2.
Output Voltage: +12 V
Output Current
Max: 2.5 A
Peak: 3.3 A
Fan: 3 A
Ripple: 150 mV
Total Regulation: ± 5.0%
