Input
Input range: 85 - 264 Vac (wide range); 120 - 300 Vdc
Frequency: 47 - 440 Hz
Inrush current:
< 18 A peak @ 115 Vac; < 36 A peak @ 230 Vac, cold start @ 25°C
Input current: 1.5 A max. (RMS) @ 115 Vac
Efficiency: 70% typical at full load
EMI: FCC Class B conducted; CISPR 22 Class B conducted EN55022 Class B conducted; VDE 0878 PT3 Class B conducted
Safety ground leakage current: <0.5 mA @ 50/60 Hz, 264 Vac input
Output
Maximum power:
60 W for convection; 80 W with 30CFM forced air
Adjustment range: -5, +10% minimum
Hold-up time: 20 ms @ 60 W load, 115 Vac nominal line
Overload protection: Short circuit protection on all outputs. Case overload protected @ 110% to 145% above peak rating
Overvoltage protection: 5V output; 5.7 to 6.7 VDC. Other outputs 10% to 25% above nominal output
Remote sense: Compensates for 0.5 V lead drop min. Will operate without remote sense connected. Reverse connection protected.
Environmental Specifications
Operating temperature: 0°C to 50°C ambient derate each output at 2.5% per degree from 50°C to 70°C, -20°C start up.
Electromagnetic susceptibility: Designed to meet IEC61000-4-2, -4-3, -4-4, -4-5, -4-6, Level 3
Humidity: Operating; non-condensing 5% to 95% RH
Vibration: Three orthogonal axes, sweep at 1 oct/min, 5 min. dwell at four major resonances 0.75 G peak 5 Hz to 500 Hz, operational
Storage temperature: -40°C to +85°C
Temperature coefficient: ±0.04% per °C
MTBF demonstrated: > 550.000 hours at full load and 25°C ambient conditions
Ordering Information
Output Voltage: 12 V
Minimum Load: 0 A
Maximum Load with Convection Cooling: 5 A
Maximum Load with 30CFM Forced Air: 6.7 A
Peak Load: 7.5 A
Regulation: ±2%
Ripple P/P(PARD): 120 mV
