Input
Input range: 90 - 264 Vac; 120 - 300 Vdc
Frequency: 47 - 63 Hz
Inrush current: 50 A max., cold start @ 25°C
Output
Maximum power: 200 - 240 W (see de-rating) for convection, 360 W with 400 LFM of forced air
Adjustment range: 12 V and 24 V models, -0%, +15%; 15 V and 48 V models, -5%, +10%; 36 V model, -15%, +0%
Standby output: 5 V @ 1A convection, 2 A with forced air
Hold-up time: 16 ms @ 250 W load, 120 Vac input
Environmental Specifications
Operating temperature:
-20 °C to 50 °C ambient, derate each output as 2.5% per degree from 50 °C to 70 °C;
-40 °C startup if Standby output ≤ 1A (any valid load on main output);
-30 °C startup if Standby output > 1A (any valid load on main output)
Storage temperature: -40 °C to +85 °C
Humidity: Operating; non-condensing 10% to 95% RH
Function: EMI/RFI, power factor, safety ground leakage curent, fan output, overload protection, overvoltage protection; power failure, remote sense
Ordering Information:
Output Voltage: 36 V
Minimum Load: 0 V
Maximum Load with Convection Cooling: 6.25 A
Maximum Load with Forced Air: 11.25 A
Peak Load: 14.62 A
Regulation: ± 2%
Ripple P/P (PARD): 360 mV
