Input
Input range:
90 - 264 Vac (Operating) Derate to 1500 W below 180 Vac input
115/230 Vac (Nominal)
TERMINAL BLOCK
Frequency: 47-63 Hz, Nominal 50/60 Hz
Input current: 20 A RMS max input current, at 100 Vac
Output
Output rating: See table 1 90 - 264 Vac (Derate down to 50% below 180 Vac)
Rated load: 3000 W maximum (Derate to 1500 W when input is <180 Vac). Derate linear to 50% from 50 °C to 70 °C
Minimum load: Main output @ 0.0 A, 5 Vsb @ 0.0 A. No loss of regulation
Functions: Overload protection (OCP) – Constant current mode; Overvoltage protection (OVP); Overtemperature protection
Environmental Specifications
Operating temperature: -40 °C to +70 °C, linear derating to 50% from 50 °C to 70 °C. Operation at -40 °C requires a 5 minute operating warm-up at -20 °C
Storage temperature: -40 °C to +85 °C
Humidity: 10 to 90%, non-condensing. Operating. Conformal coat option available
Nominal Output Voltage Set Point: 24 V
Adjustment Range:
Max I: 4.8 V - 24 V
Max Power (3000 W): 24 V - 30 V
Max I (3000 W): 125 A
Max I (1500 W): 62.5 A
Output Ripple P/P (0-50 °C): 240 mV OR 1% whichever is higher
Combined Line/Load Regulation: 1%
Trim Range ± 25%: 18 V - 30 V
“Vprog Adjustment” 0 V to 6 V (20% to 125% Vout): 4.8 V - 30 V
