Artesyn AXA01CC36-LHS ອິສເອລເຕດ 25W, 18 - 75Vin, ຄູ່, +/-15V ແລະ +/-0.84A, 25.4 x 25.4 x 10.16mm, ມີ heatsink

Width: 25.4 mm (1 in)

Height: 17.46 mm (0.687 in)

Length: 31 mm (1.22 in)

Industry: Industrial

Efficiency: 89 %

Output Power: 25 W

Input Voltage: 18 V to 75 V

Mounting Style: Through Hole

Mechanical Style: Isolated

Isolation Voltage: 1.5 kV

Number of Outputs: 2 Output

Input Voltage - Max: 75 V

Input Voltage - Min: 18 V

Input Voltage, Nominal: 48 V

Output Current-Channel 1: 840 mA

Output Current-Channel 2: 840 mA

Output Voltage-Channel 1: 15 V

Output Voltage-Channel 2: - 15 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
