Anton Paar UNHT³ HTV ຕົວທົດສອບ Ultra Nanoindentation (-150 °C ~ 800 °C)

Maximum load [mN]: 50 / 100(1)

Load resolution [nN]: 3

Load noise floor [rms] [μN]: ≤0.05

Loading rate [mN/min]: Up to 1,000

Depth range [μm]: 50 / 100(1)

Depth resolution [nm]: 0.003

Depth noise floor [rms] [nm]: ≤0.03

Data acquisition rate [kHz]: 192

Options

Heating stage up to 200 °C: ✔

Liquid testing: ✔

(1) optional

Vacuum environment for better control of the heating and protection for indenter and sample against oxidation

Fully automatic procedure for minimizing thermal drift

Variable temperature testing from -150 °C to 800 °C

Vacuum levels down to 10-7 mbar
