Measurement principle: Laser Diffraction (Mie and Fraunhofer scattering)
Measurement range: 0.01 μm - 2,500 μm
Size classes: 114 (user adjustable)
Accuracy *: better than ± 0.5 % variation***
Repeatability: better than ± 0.5 % variation***
Reproducibility**: better than ± 1 % variation***
Typical measurement duration: <10 sec
Data acquisition rate: 16 kHz
Detectors:
Type: Log-spaced photo diode array and single diodes for side and back-scattering
Angular range: 0.01° - 155°
Focal length: 300 mm
Alignment: Automatic
Instrument data:
Instrument dimensions****: 400 mm x 790 mm x 290 mm (H x W x D)
Instrument weight****: 42.3 kg (93.2 lb)
Power supply: 100 V to 240 V ±10 %, 50/60 Hz
* Defined for a monomodal latex standard and accounting for manufacturer's uncertainty of standard size.
** Defined for D50 of a polydisperse standard.
*** Sample and preparation dependent. Defined for liquid dispersion measurements.
**** Without PC and dispersion unit
