ANRITSU HR-1150E ເຄື່ອງວັດແທກອຸນຫະພູມແບບຖື (-200 ~ 800°C)
Display: LCD
Waterproof specifications: Equivalent to IPX5
Input connector: ANP
Input type: Thermocouple Input: Type E, K
Channel: 1ch
Signal source resistance: MAX.1k ohm
Measurement Range:
1°C Resolution: -200 to 800°C
0.1°C Resolution: -104.9 to 504.9°C (Switches automatically to 1°C resolution range when messured temperatures fall outside the 0.1°C resolution range.)
Measurement Accuracy:
1°C Resolution: ± (0.1% of reading +1°C)
0.1°C Resolution: ± (0.05% of reading + 0.2°C)
Reference junction compensation accuracy: ±0.2°C at 25°C±10°C
Temperature Coefficient*: ±0.03×Δt°C (Add the value obtained by multiplying the excess temp.Δt[°C] by a coefficient to the total accuracy. e.g. ±0.5°C is added at room temp. of 0°C or 50°C)
Operation Environment: 0 to 50°C, 0 to 80%RH (Non condensing)
Storage Environment: -20 to 50°C, 0 to 85%RH (Non condensing)
Battery life: approx.900h
Power supply(Dry battery): 4 AA Alkaline batteries
Power supply(AC power): -
Sampling rate: approx.200ms
Linearlizer: Digital Linearizer method (Compliant with JIS C1602-2015)
Dimensions(mm): approx. 82(w)×166(H)×36(D) [Protruded parts excluded]
Weight: approx. 350g [Include Batteries]
Supplied accessories: Manual,Test report,Soft case, Hand strap,4 AA Alkaline batteries
