Analog Devices MAX40242ANA+T Operational Amplifiers Low-Noise, Low Bias-Current Dual Amplifi

Shutdown: No Shutdown

Output Type: Rail-to-Rail

Mounting Style: SMD/SMT

SR - Slew Rate: 8 V/us

THD plus Noise: - 100 dB

Development Kit: MAX40242EVKIT

Number of Channels: 2 Channel

Supply Voltage - Max: 20 V, +/- 10 V

Supply Voltage - Min: 2.7 V, +/- 1.35 V

Ib - Input Bias Current: 2 pA

Operating Supply Current: 1.2 mA

Ios - Input Offset Current: 1 pA

Output Current per Channel: 95 mA

Vos - Input Offset Voltage: 50 uV

Maximum Dual Supply Voltage: +/- 10 V

Minimum Dual Supply Voltage: +/- 1.35 V

GBP - Gain Bandwidth Product: 10 MHz

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C

In - Input Noise Current Density: 0.3 pA/sqrt Hz

en - Input Voltage Noise Density: 5 nV/sqrt Hz

CMRR - Common Mode Rejection Ratio: 94 dB

PSRR - Power Supply Rejection Ratio: 130 dB
