Analog Devices MAX40110AYT+T Operational Amplifiers 15MHz Low Current Low Offset RRIO OpAmp

Shutdown: Shutdown

Input Type: Rail-to-Rail

Output Type: Rail-to-Rail

Mounting Style: SMD/SMT

SR - Slew Rate: 7 V/us

THD plus Noise: - 105 dB

Number of Channels: 1 Channel

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 1.7 V

Ib - Input Bias Current: 200 pA

Operating Supply Current: 750 uA

Ios - Input Offset Current: 200 pA

Output Current per Channel: 50 mA

Vos - Input Offset Voltage: 30 uV

GBP - Gain Bandwidth Product: 15 MHz

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C

In - Input Noise Current Density: 1.2 fA/sqrt Hz

en - Input Voltage Noise Density: 12.7 nV/sqrt Hz

CMRR - Common Mode Rejection Ratio: 90 dB
