Analog Devices LTC2000IY-16#PBF High Speed 16-/14-/11-B 2.5Gsps DACs

Shutdown: No Shutdown

Gain Error: 0.5 % FSR

Input Type: Parallel

Resolution: 16 bit

Output Type: Current

Unit Weight: 1.500 g

Architecture: Current Steering

Sampling Rate: 2.5 GS/s

Settling Time: 2.2 ns

Interface Type: LVDS, SPI

Mounting Style: SMD/SMT

Reference Type: External, Internal

Development Kit: DC2303A-A, DC2085A-A

Reference Voltage: 1.25 V

Moisture Sensitive: Yes

Number of Channels: 1 Channel

Number of Converters: 1 Converter

Supply Voltage - Max: 1.89 V, 3.465 V

Supply Voltage - Min: 1.71 V, 3.135 V

Pd - Power Dissipation: 2.2 W

Operating Supply Current: 720 mA

INL - Integral Nonlinearity: 1 LSB

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

DNL - Differential Nonlinearity: 0.5 LSB

SFDR - Spurious Free Dynamic Range: 76 dBc
