Analog Devices LM399AH#PBF Voltage References Prec Ref

Height: 2.66 mm

Shutdown: No Shutdown

Unit Weight: 1.801 g

Mounting Style: Through Hole

Output Voltage: 6.95 V

Reference Type: Shunt Precision References

Initial Accuracy: 2 %

Shunt Current - Max: 10 mA

Shunt Current - Min: 500 uA

Temperature Coefficient: 0.3 PPM / C

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: 0 C

Series VREF - Input Voltage - Max: 40 V
