Analog Devices ADG1204YCPZ-500RL7 Multiplexers +/- 15V 4:1 MUX ມີ LOW CAP I.C.

Width: 3 mm

Height: 0.83 mm

Length: 3 mm

Bandwidth: 800 MHz

Unit Weight: 43.800 mg

Configuration: 1 x 4:1

On Time - Max: 85 ns

Mounting Style: SMD/SMT

Off Time - Max: 110 ns

Moisture Sensitive: Yes

Number of Channels: 4 Channel

Off Isolation - Typ: 85 dB

On Resistance - Max: 190 Ohms

Supply Voltage - Max: 13.2 V

Supply Voltage - Min: 10.8 V

Pd - Power Dissipation: 1.3 mW

Operating Supply Voltage: 12 V

Maximum Dual Supply Voltage: +/- 16.5 V

Minimum Dual Supply Voltage: +/- 13.5 V

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
