Analog Devices AD676TD/883B S/H ADC IC, 16-BIT SAMPLING ADC

Width: 15.49 mm

Height: 5.34 mm

Length: 37.85 mm

Input Type: Single-Ended

Resolution: 16 bit

Architecture: SAR

Input Voltage: +/- 10 V

Sampling Rate: 100 kS/s

Interface Type: Parallel

Mounting Style: Through Hole

Reference Type: External

Sample and Hold: Yes

Number of Channels: 1 Channel

Number of ADC Inputs: 1 Input

Number of Converters: 1 Converter

Pd - Power Dissipation: 480 mW

INL - Integral Nonlinearity: 1 LSB

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 55 C
