Analog Devices AD4632-24BBCZ SAR ADC 24-Bit, 0.5 MSPS, ຄູ່

Features: Programmable block Averaging Filter

Shutdown: Shutdown

Input Type: Differential

Resolution: 24 bit

Output Type: Digital

Architecture: SAR

Sampling Rate: 500 kS/s

Interface Type: SPI

Mounting Style: SMD/SMT

Power Consumption: 5 mW

Reference Voltage: 4.096 V to 5 V

Number of Channels: 2 Channel

Number of Converters: 2 Converter

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 4.75 V

Pd - Power Dissipation: 39 mW

INL - Integral Nonlinearity: 0.9 PPM

SNR - Signal to Noise Ratio: 105.7 dB

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C

DNL - Differential Nonlinearity: 0.5 LSB

THD - Total Harmonic Distortion: - 127 dB

SFDR - Spurious Free Dynamic Range: 127 dB

SINAD - Signal to Noise and Distortion Ratio: 105.7 dB
