Analog Devices ADG5298HFZ ເມືອງຫຼາຍທາງອຸນຫະພູມສູງ (ສູງສຸດເຖິງ 210 C), ກະວັນໄຟຟ້າສູງ, ປ້ອງກັນ Latch-Up, ເມືອງຫຼາຍ 8 ຊ່ອງ

Bandwidth: 95 MHz

Supply Type: Single Supply, Dual Supply

Unit Weight: 18.490 g

Configuration: 1 x 8:1

On Time - Max: 435 ns

Mounting Style: SMD/SMT

Off Time - Max: 305 ns

Development Kit: EVAl-ADG5298EB1Z

Number of Channels: 8 Channel

Dual Supply Voltage: +/- 9 V to +/- 22 V

Off Isolation - Typ: - 86 dB

On Resistance - Max: 800 Ohms

Supply Current - Max: 155 uA

Supply Voltage - Max: 40 V

Supply Voltage - Min: 9 V

Operating Supply Voltage: 9 V to 40 V

Maximum Dual Supply Voltage: +/- 22 V

Minimum Dual Supply Voltage: +/- 9 V

Maximum Operating Temperature: + 210 C

Minimum Operating Temperature: - 55 C
