ams OSRAM SFH 310-2/3 ຊິລິກອນ NPN ໂຟໂຕທຣານຊິສຕໍ PHOTOTRANSISTOR

Width: 3.4 mm

Height: 4.8 mm

Length: 3.4 mm

Fall Time: 8 us

Rise Time: 8 us

Wavelength: 880 nm

Unit Weight: 200 mg

Dark Current: 50 nA

Light Current: 2 mA

Qualification: AEC-Q100

Mounting Style: Through Hole

Peak Wavelength: 880 nm

Lens Color/Style: Clear

Pd - Power Dissipation: 165 mW

Half Intensity Angle Degrees: 25 deg

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 40 C

Maximum On-State Collector Current: 50 mA

Collector- Emitter Voltage VCEO Max: 35 V

Collector-Emitter Breakdown Voltage: 35 V

Collector-Emitter Saturation Voltage: 150 mV
