Amphenol Piher PC16SH07IP21224A1010TA Multimedia 220K OHM

Life: 25000 Cycle

Taper: Linear

Width: 16 mm

Height: 8 mm

Length: 18 mm

IP Rating: IP54

Tolerance: 10 %

Resistance: 220 kOhms

Shaft Type: Flatted / D

Orientation: Horizontal

Switch Type: No Switch

Thread Size: M7

Unit Weight: 6.558 g

Element Type: Carbon

Power Rating: 200 mW (1/5 W)

Shaft Length: 12.7 mm

Bushing Thread: M7 x 0.75

Mounting Style: PCB Mount

Shaft Diameter: 4 mm

Voltage Rating: 250 VDC

Number of Gangs: 1 Gang

Number of Turns: 1 Turn

Number of Detents: Without Detent

Termination Style: PC Pin

Temperature Coefficient: 300 PPM / C

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 25 C
