AMP Connectors - TE Connectivity 284229-1 ກະເປົາ MQS 20 + 20 POS. CONN. KIT

Color: Blue

Pitch: 2.54 mm (0.1 in)

Width: 23.5 mm

Gender: Receptacle (Female)

Height: 54 mm

Length: 54 mm

Application: Signal

Row Spacing: 5.2 mm

Unit Weight: 14 g

Contact Type: Socket

Contact Gender: Without Socket Contacts

Mounting Angle: Right Angle

Mounting Style: Cable Mount / Free Hanging

Number of Rows: 4 Row

Voltage Rating: 24 VDC

Wire Gauge Max: 20 AWG

Wire Gauge Min: 22 AWG

Housing Material: Polyamide (PA)

Wire Gauge Range: 22 AWG to 20 AWG

Lock Mate Feature: On the terminal

Termination Style: Crimp

Number of Positions: 40 Position

Description/Function: MQS Connector Housings

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
