Altera EM2030L01QI ຕົວແປລະດັບລົງ DC-DC ປະຕິບັດງານພ້ອມກັນ 30A PowerSoC

Shutdown: Shutdown

Topology: Buck

Input Voltage: 4.5 V to 16 V

Mounting Style: SMD/SMT

Output Current: 30 A

Output Voltage: 500 mV to 1.325 V

Load Regulation: 0.07 mV/A

Number of Outputs: 1 Output

Quiescent Current: 40 mA

Moisture Sensitive: Yes

Input Voltage - Max: 16 V

Input Voltage - Min: 4.5 V

Switching Frequency: 800 kHz

Supply Voltage - Min: 4.5 V

Operating Supply Current: 40 mA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
