Capacity F(nom) (N) : 50N
Resolution (N) : 0.01
Temperature coefficient (% / K ) : 0.02
Reproducibility (% F ) : 0.03
Repeatability( % F) : 0.03
Hysteresis (% F ) : 0.075
Creeping (5min) (% F ) : 0.15
Measuring principle : Bidirektionaler Kraftsensor mit Dehnungsmessstreifen und High-Speed ?-Prozessor
Nominal deflection( mm) : 0.13
Measuring shaft : M6
Max. operating force (% F(nom)) : 120
Breaking force (% F(nom)) : 500
Display:
Type: 5-digit LCD | 12mm | Autoreverse
Refresh time (ms) : 10 ... 1000
Operation modes:
Regular: N | kg | lb
Peak (real-time) : Display of peak value | Peak value of pull- or push force (drag indicator function)
Limits + Statistik : 2 separately adjustable limits | Single value memory and continuous measured value memory
Interface:
USB : USB 2.0 data communication
Hirose : Limit / overload signals. digital I/O's (1 input / 3 outputs). trigger. supply (optional data cable required)
Sensor : Parallel. time-synchronous data acquisition for force and distance
Power supply:
Type S: olar cell | USB (max. 900 mA)
Connection : USB (socket)
Temperature (operation) (°C 0) : ... 40
Protection code (EN 60529) (Cable not plugged) : IP40
Housing:
Material : Aluminium die cast
LxWxH (mm): 150 x 82 x 29
Weight (kg): 0.48
Mounting : 2xM4. 2xM5. adjusting holes D5(H7)
