Capacity F(nom) (N) : 250N
Resolution (N) : 0.05
Temperature coefficient (% / K) : 0.02
Repeatability (% F) : 0.03
Creeping (5min) (% F) : 0.15
Measuring principle: Bidirectional force sensor with strain gauges and high-speed ?-processor
Nominal deflection ( mm) : 0.23
Measuring shaft : M6
Max. operating force % F(nom) 120 :
Breaking force % F(nom) : 500
Display:
Type : 5-digit | 12mm | Autoreverse
Refresh time (ms) : 10 ... 1000
Operation modes:
Regular: N | kg | lb
Peak (real-time): Display of peak value | Peak value of pull- or push force (drag indicator function)
Limits + Statistik: 2 separately adjustable limits | Single value memory and continuous measured value memory
Interface:
USB: USB 2.0 data communication
Hirose: Limit / overload signals. digital I/O's (1 input / 3 outputs). trigger. supply (optional data cable required)
Sensor: without
Power supply:
Type: Solar cell | USB (max. 900 mA)
Connection: USB (socket)
Temperature (operation) °C: 0 ... 40
Protection code (EN 60529) Cable not plugged: IP40
Housing:
Material : Aluminium die cast
LxWxH (mm) : 150 x 82 x 29
Weight (kg) : 0.48
Mounting: 2xM4. 2xM5. adjusting holes D5(H7)
